E30CNC Specs.

CAPACITIES:
          Max Tool Diameter for Auto-Load with 8" diameter wheel:            0.5000"      12.7 mm
          Max Tool Diameter for Hand-Load with 8" diameter wheel:           0.7500"      19.05 mm
          Min Tool Diameter for Auto-Load:                                                0.1250"      31.75 mm
          Max Length Of Grind:                                                                   4.0"            101.6 mm
          Max Overall Length Of Tool (To Auto Load):                               6.0"            152.4 mm


WHEELHEAD AXES:
          X Slide                                                         7.5" (190.4 mm), repeatability 0.0002"
          Z Slide                                                         9.0" (228.6 mm), repeatability 0.0002"


TOOLHEAD AXES:
          Y Slide                                                               7.5" (190.4 mm), repeatability 0.0002"
          A Rotary                                                            (Work Spindle) free rotation, resolution 0.0001º


FEEDRATES:
          Linear Axes                                                        0-200 IPM
          Rotary A Axis                                                    500 RPM


WHEELHEAD:
          Wheel Spindle RPM                                           3000 RPM
          Wheel Diameters                                                6"-8"
          Spindle HP                                                         3 HP


CONTROL:
          Intel Pentium controlled 3-axis CNC controller. (Basic E60CNC Control)
          Capable of 2-axis circular interpolation for complex movement profiles.
          Digital AC servos.
          Excalibur Conversational tool programs, written in-house by Excalibur.
          Excalibur Special Programming, (Enhanced G-Code) for free-programming.
          Software technical support by tool grinding experts.


INTEGRATED AUTO-LOADER:
          Blanks are loaded from an interchangeable magazine by a pneumatic plunger.
          Fixed size magazines are quickly changed out for the next size run.


DIMENSIONS:
          Weight                                                              900 lbs.          .45 tons
          Floor Area, Machine                                         60" X 60"      1.5 m X 1.5 m


EXCALIBUR TRAINING:
          2-3 days of personalized training by our experts at our plant.
          Option:  Training at your plant.


WARRANTY:
          1 year or 2000 hours on parts and labor.  Service by Excalibur
          or local agent.
HOME

PRODUCTS

CONTACT  US

SALES/SERVICE

ASK JOHN
E30CNC
The E30CNC Plunge Grinder is an automatically loaded CNC OD grinder designed to plunge or profile grind the shanks of HSS or Carbide cutting tool blanks from 1/8" to 1/2" diameter. Blanks are loaded from an interchangeable magazine by a pneumatic plunger, plunge ground to +/-0.0001" diameter, and are ejected to a gravity feed chute.
