OMEGA45 Specs.

CAPACITIES:
          Max Tool Diameter:                                            0.375"         9.53 mm
          Min Tool Diameter:                                             0.030"         0.76 mm
          Max Length of Grind:                                          3.0"             76.2 mm
          Max Overall Length of Tool:                         8.0"             304.8 mm


WHEELHEAD AXES:
          Y Slide                                      5.0" (127 mm), repeatability 0.0002"
          C Rotary (pneumatic)                       0 to 35º left or Right


TOOLHEAD AXES:
          X Slide                                            11" (279.4 mm), repeatability 0.0002"
          Z Slide                                      7.0" (177.0 mm), repeatability 0.0002"
          A Rotary                                         (Work Spindle) free rotation, resolution 0.005º


FEEDRATES:
         All Linear Axes                                0-200 IPM
          Rotary A Axis                                 150 RPM
          Rotary C Axis                                 Pneumatic


WHEELHEAD:
         Wheel Spindle RPM                       3600 RPM
          Wheel Diameters                            4"-6" (6" RH Only)
          Spindle HP                                     1.5 HP (10 HP optional)


CONTROL:
          Intel Pentium controlled 6-axis CNC controller.
          Digital AC servos drive all linear axes.
          Excalibur Conversational tool programs, written in-house by Excalibur.
          Optional programs available at no extra charge; Stepdrills,
          Reamers, Routers, Tapered Mills.


DIMENSIONS:
          Weight                                           1800 lbs.          .9 tons
          Floor Area, Machine
          Controls and coolant                      36" X 48"        .914 m X 1.22 m


EXCALIBUR TRAINING:
          40 hours of personalized training by our experts at our plant.
          Option:  Training at your plant.


WARRANTY:
          1 year or 2000 hours on parts and labor.  Service by Excalibur
          or local agent.
OMEGA45
The Solution For:
  • Maximizing shop space.
  • Standard end mills in one clamping.
  • Diamond cut routers in one clamping.
  • Straight and tapered burrs.
  • Double-End end mills.
  • High quality "specials" to 3/8"
  • A "dedicated" manufacturing center
