Two-axis CNC attachment, designed to convert a manual tool and cutter grinder into an automated CNC machine tool. The EXCALIBUR A2CNC is designed to flute-grind solid carbide and HSS cutting tools. It is engineered for maximum reliability and ease of use. more.
The ERG-6 RoboGrind is designed to manufacture end mills, drills, routers, and burrs in one chucking. It has 6 CNC axes and superb accuracy to produce tools from 1/32" to 3/8" diameter.
The FANUC robot provides automated loading and unloading and is precise enough for handling doubled ended tools without chipping. more.
The unique layout of the E60 allows a multitude of cutting tools to be ground in one chucking. Applications include, but are not limited to, the manufacturing of end mills, twist drills, reamers, slitting saws, and thread mills. The diameter range of the E60 is 0.0100" to 1.0000", and flutes as long as 4.0000" may be ground. more.
The E45 is designed to manufacture small end mills from solid blanks in ONE chucking. It has four CNC axes and one pneumatic axis. The E45 has superb accuracy to produce tools from 1/32" to 3/4" diameter, straight or helical flute to 60 degree spiral. more.
The OMEGA45 is designed to maximize your shop space with a foot print of 36" x 48" including the 38 gallon coolant tank. The OMEGA45 has superb accuracy to produce small end mills from a solid blank 1/32" to 3/8" diameter in ONE chucking. It has four CNC axes and one pneumatic axis. It's an unbeatable value! more.
Excalibur's grinding machines range from the 2 axis A2CNC attachment to our latest product the ERG-6 RoboGrind.
Whether you need a full featured start to finish grinder, a plunge grinder or something in between Excalibur Tool has the machine you need to get your tools out the door quickly.
The E30CNC Plunge Grinder is an automatically loaded CNC OD grinder designed to plunge or profile grind the shanks of HSS or Carbide cutting tool blanks from 1/8" to 1/2" diameter. Blanks are loaded from an interchangeable magazine by a pneumatic plunger. Fixed size magazines are quickly changed out for the next size run. Parts are plunge ground to +/-0.0001" diameter, and are ejected to a gravity feed chute. Tapers, Radii, or Steps may be accurately OD ground in one chucking. more.
